Main

Cholestatic jaundice is the major complication of TPN in infancy. Despite 30 y of clinical experience with TPN, the cause of the liver damage remains unknown. The only effective treatment is to discontinue the TPN and provide all calories and essential nutrients enterally. When this is not possible, progressive liver damage leads to cirrhosis and death.

A previous investigation in our laboratory has shown that the TPN solution itself is directly hepatotoxic and that this toxicity appears to be mediated by one or more sulfur-containing amino acids(1). Specifically, serum methionine level was markedly elevated in animals on TPN compared with controls. The objective of this study was to determine whether infusion of methionine into normally fed rabbits injured the liver in a manner similar to TPN.

METHODS

Nine-week-old New Zealand White rabbits (n = 28) were divided into three groups. The FED group (n = 10) was fed standard rabbit chow ad libitum. The TPN group (n = 9) was not fed and received only i.v. TPN (including methionine 121 mg·kg-1·d-1) and lipids. The experimental (EXP) group (n = 9) was fed rabbit chow ad libitum and received i.v. methionine (121 mg·kg-1·d-1). The study was approved by the institution's animal care and use committee.

Surgical and anesthetic technique has been previously described ((1)). The TPN solution consisted of crystalline amino acids (Aminosyn 10%, Abbott, Chicago, IL) delivered at 3.6 g·kg-1·d-1 and glucose at 14.4 g·kg-1·d-1. Lipids (Intralipid 10%, KabiVitrum Inc., Alameda, CA) were provided at 4 g·kg-1·d-1. Methionine was dissolved in saline and infused continuously via a central venous catheter.

After 14 d on the prescribed diets, we anesthetized the animals, performed a laparotomy, and cannulated the bile duct. We evaluated bile flow rate, excretion of BSP, serum liver enzymes, and liver histology. BSP is an easily measured dye that is taken up by the liver and excreted into bile in a similar manner to bilirubin. We collected blood for amino acid analysis and serum liver enzyme measurement.

Bile flow was determined gravimetrically. BSP concentrations in bile were determined colorimetrically. Homocysteine and cysteine levels were determined by the method of Jacobsen et al.(2). Other amino acids were determined by the Picotag method(3). Liver samples were fixed immediately in formalin, and sections were stained with hematoxylin and eosin and examined by light microscopy.

Results are expressed as mean and SD. Statistical comparisons between groups were made by means of the unpaired t test. Significance was defined as p < 0.05.

RESULTS

Administration of i.v. methionine to normally fed animals injured the liver. We observed significant alterations in hepatobiliary function and liver histology. These changes were similar to but less severe than those seen in animals receiving TPN. Animals in all three groups tolerated their diets well and were healthy at the time of analysis. Weight gain was similar in all groups (approximately 5 g/day).

Bile flow was significantly depressed not only in animals receiving TPN, but also in animals fed a regular diet supplemented by i.v. methionine (Table 1). Excretion of the exogenous dye, BSP, was significantly delayed in the TPN group. It appeared to be delayed in the EXP group as well, but this difference did not achieve statistical significance. Serum liver enzymes, including aspartate transaminase, alanine aminotransferase, γ-glutamyltransferase, and alkaline phosphatase, were normal in all groups.

Table 1 Effect of nutrient infusions on hepatobiliary function
Full size table

The appearance of the liver of animals fed a normal diet plus i.v. methionine was remarkably similar to that of animals on TPN. Grossly, the livers were swollen and green. In comparison with the normal liver of the FED group we observed balloon degeneration of hepatocytes and an infiltration of the portal triads with eosinophils in the liver of animals on TPN (Figs. 1 and 2). We identified precisely the same abnormalities in normally fed animals receiving i.v. methionine (EXP) (Fig. 3). The only difference between the TPN and EXP groups was that there were some areas of preserved architecture in the EXP group.

Figure 1
figure 1

Histologic appearance of the liver in the FED group. The hepatocytes have a homogeneous pink cytoplasm, they are orderly arrayed, and the portal triads are free of inflammatory infiltrate.

Full size image
Figure 2
figure 2

After 14 d of TPN, the hepatocytes are ghostlike with balloon degeneration of the cytoplasm. There is an infiltrate with eosinophils (arrow) and early bile duct proliferation.

Full size image
Figure 3
figure 3

In the FED group, the changes were remarkably similar to those seen with fasted animals on TPN. The hepatocytes are grossly abnormal with balloon degeneration, there is an infiltrate around the portal tracts with eosinophils (arrow), and there is early proliferation of bile ductules.

Full size image

We next measured the serum levels of the methionine metabolites homocysteine and cysteine (Table 2). Homocysteine levels were elevated in the TPN and EXP groups. The difference in the TPN group was not statistically significant. The cysteine concentration was low in the group receiving only TPN.

Table 2 Serum levels of methionine metabolites
Full size table

DISCUSSION

Cholestatic jaundice remains the most important complication of TPN in infants(4). The only known treatment for TPN cholestasis is to stop the TPN and provide full nutrition by the gut; usually a clinical impossibility. Improved perioperative care of the neonate with complex gastrointestinal disease has increased survival but usually at the expense of prolonged parenteral support(5). These patients typically are in a race to recover gastrointestinal function before they succumb to the progressive liver disease caused by TPN(6).

Our previous investigations using this rabbit model led to the surprising finding that TPN cholestasis is caused by the solution rather than the i.v. route of delivery(1). We saw the same kind and extent of liver injury whether TPN solution was given by vein or by gut. This contrasts with the prior conclusion that cholestasis is caused by an absence of oral feeding and gut stimulation. We reported previously that in the clinical setting babies on TPN experience progressive liver disease even when 25% of their calories are provided orally(7).

TPN consists of glucose, lipids, and amino acids. We hypothesize that one or more of these agents is hepatotoxic. Excess glucose may cause steatosis but does not cause cholestasis(8). TPN cholestasis was described before i.v. lipids came into clinical use(9). Neither human nor animal studies have found differences in hepatic indices during TPN with or without lipids(10–12). In contrast, both experimental and clinical studies have suggested amino acids cause cholestasis(13–16).

We believe that it should be possible to formulate a TPN solution that does not injure the liver. Perhaps the most compelling argument that suggests this assertion is the fact that a fetus develops a normal liver despite complete parenteral alimentation. In the current study, we have shown that i.v. methionine, at concentrations present in current TPN solutions, injures the liver of normally fed animals.

Methionine levels are elevated during TPN(1). Methionine is an essential sulfur-containing amino acid that is metabolized via the trans-sulfuration pathway shown in simplified form in Figure 4. Abnormalities of the trans-sulfuration pathway may allow methionine to accumulate to excess. This could harm the liver in two ways. First, methionine has been shown to be the most hepatotoxic amino acid(17,18). Abnormally high levels of methionine have been implicated in hepatic injury by a variety of mechanisms.

Figure 4
figure 4

The trans-sulfuration pathway. Many biochemical intermediates and pathways have been omitted for clarity.

Full size image

Second, disruption in the trans-sulfuration pathway increases the liver's susceptibility to oxidative damage. Methionine is a substrate in the synthesis of glutathione in the liver. Glutathione, in its reduced form, is necessary to protect the liver from oxidative injury. In the first step of the transsulfuration pathway, the adenosyl moiety of ATP is added to methionine and one equivalent of ATP is consumed. When given in excess, methionine drastically depletes the liver's ATP reserves(18). This results in a marked shift in hepatic glutathione from its reduced GSH form to its oxidized GSSG form(19). The liver then becomes increasingly susceptible to oxidative injury. A metabolic block within the trans-sulfuration pathway will prevent restoration of liver glutathione levels while allowing methionine to accumulate at toxic levels.

Studies in adults with cirrhosis have confirmed that impairment of the trans-sulfuration pathway leads to methionine excess and a shortage of reduced glutathione(20–22). In fact, the severity of cirrhosis has been correlated with the degree of impairment of the trans-sulfuration pathway(23). We did not measure glutathione levels in this study; further work will answer this important question.

Although excess methionine may damage the adult liver, its effects in the neonate are amplified many fold. The neonate is poorly equipped to handle excess methionine and acutely susceptible to its toxic effects. In human neonates, the trans-sulfuration pathway is immature and only partially functional(24). Specifically, the enzyme cystathionase functions poorly in the neonate(25). Our finding of elevated homocysteine levels is consistent with a blockage at the level of cystathionase.

Methionine levels are elevated in serum after just 1 wk of TPN in human infants(26,27). In infants who died of TPN cholestasis and cirrhosis, methionine levels were markedly elevated shortly before death(28). In animal models, TPN is associated with rapid depletion of liver glutathione. After only 5 d, TPN decreases hepatic glutathione concentration in neonatal rats(29).

We propose that methionine levels in current TPN solutions may be too high for the neonate and could precipitate the liver injury caused by TPN. Our data demonstrate significant functional and structural hepatic injury after 14 d of i.v. methionine. We believe that methionine may be an important factor in the pathogenesis of TPN-associated cholestasis in the neonate. Further studies are needed to elucidate the mechanism of methionine-induced liver damage. Modification of the TPN solution to lower the methionine concentration while providing alternative intermediates to the trans-sulfuration pathway may significantly alleviate cholestasis seen with TPN. These studies are currently in progress.
